DESCRIPTION
Near field communication (NFC) is a set of standards for smartphones and similar devices to establish radio communication with each other by touching them together or bringing them into close proximity, usually no more than a few centimeters.NFC is a popular technology in recent years. Most companies have introduced their latest high-end phones. Almost all the high-end phones in the market support NFC. Users could easily connect and play.The PN532 is the most popular NFC chip and is what is embedded in pretty much every phone or device that does NFC. With our Arduino Uno, Raspberry Pi Zero W compatible Sensor module, it is very easy to plug and play.It is an extension of RFID, so anything you can do with RFID you can do with NFC.However, if users want to use other interfaces such as UART or SPI, this module also makes it easy to connect those pins.
DEVELOPMENT SOURCES
FEATURES
- Support II2, SPI, and HSU (High-Speed UART)
- RFID reader/writer mode support
- Mifare 1k, 4k, Ultralight, and DESFire cards
- ISO/IEC 14443-4 cards such as CD97BX, CD light, DesFire, P5CN072 (SMX)
- Innovision Jewel cards such as IRT5001 card
- FeliCa cards such as RCS_860 and RCS_854
- Plug and play IOT & Robotics, Arduino, Raspberry Pi Zero W compatible
- On-board level shifter, Standard 5V TTL for I2C and UART, 3.3V TTL SPI
- Work as RFID reader/writer 7. Work as 1443-A card or a virtual card
- Support NFC with Android phones. Small size: 43mm*41mm*4mm
- Built-in PCB Antenna, with 5cm~7cm communication distance
